產品型號：X系列 原產地：臺灣 品牌：TPC 產品說明： 1.檢出方式：擴散反射／鏡片反射／對照型 2.感應距離：擴散反射（70 cm）／鏡片反射（4 m）／ 對照型（10 m） 3.輸出方式：NPN NO/NC,PNP NO/NC 4.工作電壓：DC10-30V 5.電線材質：PVC耐油電線 6.保護等級：IP66 7.防水性佳 擴散反射:
型號 | 工作電壓 | 感應距離 | 應差距離 | 輸出方式 | 消耗電流 | 負載電流 | 殘留電壓 | 反應頻率 | 重量 |
Type | Power Supply | Sensing Distance | Differential Travel | Output | Current Consumption | Load Current | Voltage Drop | Response Frequency | Wieght |
XDD-70N | 10-30V DC | 70cm | ±15% | NPN NO/NC | ﹤30mA | 250mA Max. | 1V Max. | 1.5ms Max. | 90g |
XDD-70P | 10-30V DC | 70cm | ±15% | PNP NO/NC | ﹤30mA | 250mA Max. | 1V Max. | 1.5ms Max. |
鏡片反射:
型號 | 工作電壓 | 感應距離 | 應差距離 | 輸出方式 | 消耗電流 | 負載電流 | 殘留電壓 | 反應頻率 | 重量 |
Type | Power Supply | Sensing Distance | Differential Travel | Output | Current Consumption | Load Current | Voltage Drop | Response Frequency | Wieght |
XRD-400N | 10-30V DC | 4M | ±15% | NPN NO/NC | ﹤30mA | 250mA Max. | 1V Max. | 1.5ms Max. | 100g |
XRD-400P | 10-30V DC | 4M | ±15% | PNP NO/NC | ﹤30mA | 250mA Max. | 1V Max. | 1.5ms Max. |
對照型;
型號 | 工作電壓 | 感應距離 | 應差距離 | 輸出方式 | 消耗電流 | 負載電流 | 殘留電壓 | 反應頻率 | 重量 |
Type | Power Supply | Sensing Distance | Differential Travel | Output | Current Consumption | Load Current | Voltage Drop | Response Frequency | Wieght |
XTD-1000N | 10-30V DC | 10M | ±15% | NPN NO/NC | ﹤30mA | 250mA Max. | 1V Max. | 1.5ms Max. | 165g |
XTD-1000P | 10-30V DC | 10M | ±15% | PNP NO/NC | ﹤30mA | 250mA Max. | 1V Max. | 1.5ms Max. |
